DW-EC Series Class B Table Top Autoclave
- Inductive closing door: Inductive vacuum inductiave lid while closing, automatic lock releasing and open after sterilization.
- High pressure hydraulic test: The instrument meets the latest national standards and has passed a water pressure test of up to 0.75Mpa (design test).
- Steam generator: Powerful steam generator with fast heating speed.
- Vacuum pump: Original imported vacuum pump from Germany, with good vacuum effect.
- Reinforced steel plate: Sealing door with reinforced steel plate with a thickness of>8mm, effectively ensuring the safety of the sealing door.
- Intelligent drying function: No need to set the drying time, the drying time can be controlled automatically by system based on the sample size.
Intelligent Features of DW-EC Series Class B Table Top Autoclave
- Control system: Smart microcomputer control system.fully automatic control the sterilization process.
- Auto start up appointment: Can schedule sterilization and automatically start
- F0 value caculation: F0 value is automatically caculated, can print out by micro-printer.
- Program memory function: User can set their own program, and save in the system.
- Data reading and curve conversion: Provide USB interface for easy reading or storage of sterilization data. The sterilization data is converted into curves for easy data analysis.
- Sterilization record storage: Built in large capacity memory, can store 999 sterilization cycles and can be queried, printed or exported for easy traceability management.
- 5 level access permission: The operation permissions for instruments are divided into five levels, with each level of user having an independent password and multiple IDs that can be assigned. Each level of user has limited access to certain usage permissions.
Safety Features of the DW-EC Series Class B Table Top Autoclave
DRAWELL has always prioritized safety since its establishment, adhering to the highest industry standards and providing multiple safety guarantees from design, manufacturing.use,application to service.
- Smart interlocking: Only when the temperature and pressure are safe inside, can the door be opened.If the door is not closed in place, it cannot start working.
- Water shortage prevention: Both the open water storage tank and steam generator are equipped with water level sensors, and automatic alarm for water shortage.
- Double protection for over pressure: Equipped with a safety valve and overpressure protection system, if the pressure is abnormal, immediately release the pressure,cut power and send out alarm.
- Over temperature and temperature rise protection: Power cut and alaraming sent, if there is temperature is too high or themperature rising is abnormal.
- Electrical protection: Prevention for over current,short ciucuit and electricity leakage.
DW-EC Series Class B Table Top Autoclave Structure
Technical Specifications of DW-EC Series Class B Table Top Autoclave
| Model | DW-EC14GP | DW-EC18GP | DW-EC23GP |
| Capacity(L) | 14 | 18 | 23 |
| Dimension(L*W*H)(mm) | 728x534x416 | 728x534x416 | 728x534x416 |
| Chamber dimension(Dia*H)(mm) | Φ 230×358 | Φ 246×397 | Φ 246×483 |
| Net weight | 60kg | 68kg | 81kg |
| Rated power(W) | 1500W | ||
| Chamber material | S30408 | ||
| Sterilization temperature | 115°C ~135°C | ||
| Sterilization time range | 1~999 min | ||
| Appointment timer range | 0~15 days | ||
| Pulse times | 1~5 times | ||
| Exhaust mode | Automatic internal discharge | ||
| Water tank capacity | 8.5 L | ||
| Drying | Drying temp.:80°C~180°C Drying time:1-300 min(Free of setting for smart drying) | ||
| Vacuum | Vacuum degree<-92kpa Vacuum leakage rate<0.13kpa/min | ||
| Safety valve set pressure | 0.29MPa | ||
| Sterilization mode | Fabric: Preheat→Vacuum→Heating→Pulse-Sterilizing→Exhausting→Drying→End Device: Preheat-Vacuum→Heating→Pulse-Sterilizing→Exhausting→Drying→End Liquid: Preheat-Heating-Sterilizing-Exhausting-End(Set by engineer account) Drainage: Heating-Sterilizing-Drainage-End(Set by engineer account) Drying: Drying→End BD test: Preheat-Vacuum→Heating→Pulse-Sterilizing→Exhausting→End Vacuum test: Vacuuming-Test-End | ||
| Special function | USB port, printer can print temperature and pressure curve and FO valve(option) | ||
| Controller | “Inspiration Ш” microcomputer intelligent control system | ||
| Safety device | Lid closing checking, over temperature protection system, dry scorch protection. over pressure protection, safety valve, over current/short circuit/electric leakage protection, scald protection, automatic failure-inspection system | ||
| Standard parts | Basket(l pcs),Tray( 5 pcs for 23L,4 pcs for 14L/18L) | ||
| Option | Micro-printer, Sterilization box | ||
