Handheld X-Ray Fluorescence Spectrometer (XRF)
Handheld X-Ray Fluorescence Spectrometer (XRF)
A handheld X-ray fluorescence spectrometer (XRF) is a portable, non-destructive, rapid elemental analysis instrument that can directly determine the elemental composition and content of solid, powder, and liquid samples on-site. Its principle involves emitting high-energy X-rays from an X-ray tube to excite sample atoms, causing them to release characteristic fluorescence. This fluorescence is then captured and analyzed by a detector to identify the element and its content.
Handheld XRF are widely used in ore exploration, metal recovery/alloy analysis, precious metal identification, soil heavy metal screening, material screening, RoHS compliance screening, and catalyst toxicity analysis.
Drawell provides you with two types of XRF – Handheld XRF and Desktop XRF.
Features of Handheld XRF
- Compact, lightweight, portable
- 1–2 s rapid analysis
- High-accuracy detection
- No sample preparation
- Non-destructive testing
- Direct surface measurement
- Multilingual customization
- Multi-modes, customizable
- Smart error correction
- Stable in harsh environments
- Triple safety protection
- 2 s auto X-ray shutoff
- Dual 9000 mAh, 8 h runtime
- AC & car charging
- HD camera + touch screen
- Remote connection support
- Custom report export
- Waterproof, dustproof, rugged
What Elements Can Drawell Handheld XRF Analyzer Measure?
Drawell provides preset calibration curves for different applications and recommends the following equipment:
Portable XRF for Mineral
Elements related to ore grade, such as Ti, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, Hf, Ta, W, Hg, Se, Au, Br, Pb, Bi, Zr, Nb, Mo, Ag, Cd, Sn, Sb, Re, Ir, Pt, Hg, Ru, Rh, and Pd.
Drawell XRF Recommends:
Portable XRF for Alloy
Elements related to alloys/stainless steel, such as Ti, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, Zr, Nb, Mo, Sn, Hf, Ta, W, Pb, Bi, Zr, Cd, Sb, Re, In, Au, Ag, Pt, Pd, Ru, Rh, and Ir.
Drawell XRF Recommends:
Portable XRF for Precious Metal
Au, Ag, Pt, Cd, Co, Cr, Cu, Fe, In, Ir, Mn, Ni, Pb, Pd, Rh, Ru, Sb, Sn, Ti, Zn, and other precious metal elements, jewelry, etc.
Drawell XRF Recommends:
Portable XRF for RoHS
Pb, Hg, Cd, Cr, Br (these four hazardous elements).
Drawell XRF Recommends:
Portable XRF for Soil
Heavy metal contaminants, such as As, Cd, Cr, Cu, Hg, Ni, Pb, Zn, Co, V, Se, etc.
Drawell XRF Recommends:
Portable XRF for Catalyst
Various catalysts including Hg, Cd, Pb, As, Cu, Zn, Ni, Co, V, Cr, Mn, Ti, Ba, Rb, Sr, Zr, Fe, etc.
Drawell XRF Recommends:
Composition of Handheld X-ray fluorescence Analyzer
Handheld XRF analyzer using an integrated group of instrument components that are sealed in an ergonomically designed, lightweight body. They include:
- Controller
- Color touchscreen(ergonomically mounted interactive display)
- Choice of detectors(PiN or SDD) to meet wide-ranging application goals
Coordinated with these robust characteristics, the instrument`s key feature is Truex`s proprietary control, data acquisition, and analysis software with customer-configured options.
Additional accessories (standard and optional) include:
- Li-lon batteries (2) – {Standard}
- Batterie charging station – {Standard}
- Rugged waterproof carry case – {Standard}
- Portable test stand to create a TrueX workstation – {Optional}
Applications of Handheld XRF
- Environmental protection: analysis of heavy metals in soil; analysis of harmful metals in paints, paints, pigments, and plastics
- Metal identification, scrap metal classification
- Petrochemical industry, catalyst, and additive element analysis
- QC/QA in metal production, casting, etc.
- Pharmaceutical Biomedicine
- Geological and mineral fields: mines, ore analysis, mineral analysis, beneficiation process control
- Material field: component analysis and quality control of refractory materials, glass, ceramics, cement, etc.
Can Light Elements in Aluminum Alloys be Tested Using XRF?
Some XRF models can test for light elements such as magnesium (Mg), aluminum (Al), silicon (Si), phosphorus (P), and sulfur (S).
- An XRF with an SDD detector is required for testing.
- Helium purging or a vacuum pump accessory is required to eliminate interference from argon in the air.
Different Applications of Spectrophotometer
| Application | Spectrophotometer Type | Picture | Model |
| Gold in Ore, Metallurgy. Geology, Mining, Petroleum. Cement, Soil, Medicine, etc. |
AAS |  |
DW-AA320N |
| Alloy, Mineral, Precious Metal, RoHS, Catalyst etc. | XRF |  |
DW-NP-5010 |
 |
EDX3600H | ||
 |
TrueX 900 | ||
 |
EDX800 | ||
| MaterialsAnalysis, Geology, Petrochemicals, Biology, Cement, Soil, Cosmetics, Food, etc. |
ICP-AES |  |
ICP700T |
| Foundry, Steel, Metal Recovery, Smelting, MilitaryAerospace, etc. | Full Spectrum Direct Reading Spectrometer |  |
DW-TY9000 |
How to Choose the Handheld XRF Model?
The user needs to provide the application field used, what is the sample to be tested, what elements need to be detected, what is the detection level, ppm or ppb, and so on. Then we will recommend the appropriate product model.
Order Process of Handheld XRF
Why Choose Us for Handheld XRF?
“Multiple suppliers” have always been an issue in the procurement process. Drawell as a one-stop laboratory equipment and scientific instruments supplier, can perfectly solve this problem. In addition to manufacturing our own equipment, we also represent other laboratory equipment. Our product lines are rich and diverse at competitive prices. Provide one-stop service to customers.
User Training – Training by Drawell skilled engineers about installation, debug tests, technical services, etc. It can happen in our factory in China, or at the site in the customers’ country. Cost depends on where and when the training happens.
To discuss the problem and get it resolved, online chats, real-time video calls, and remote guidance. For the after-sales stage, our online technical guidance is free and ready forever.
1 year free official warranty, including repairing quality-damaged parts, and offering replacements of selected parts (shipping cost is extra). 5% of the product price is charged for extending the warranty before the end of the official warranty.
