Kjeldahl Analyzer DW-K1160

DW-K1160 Automatic Kjeldahl Protein/Nitrogen Analyzer is unique in its intelligence, efficiency, energy saving and data sharing, bringing more new experiences to users. The product can be widely used in the fields of food processing, feed production, tobacco, animal husbandry, soil fertility, environmental monitoring, medicine, agriculture, scientific research, teaching, quality supervision and other fields of nitrogen or protein determination.

Fully automatic distillation and titration with optional 24-position autosampler.
FDA 21 CFR Part 11 and GMP compliant with audit trail and user management.
Burette resolution: 0.2–1 μL/step.
Up to 30% faster analysis and 50% lower water consumption.

Description
Specification
Why Drawell?

Features

Up to 24-position autosampler for high-throughput batch testing.
Side-distillation and variable-speed titration reduce analysis time by approximately one-third.
10-inch HD touchscreen with Android OS for real-time process control and easy operation.
Integrated titration module and real-time titration curves improve accuracy and method optimization.
Real-time condensate temperature monitoring ensures complete condensation and reliable results.
Separate cleaning and testing positions help prevent cross-contamination.
Large-capacity reagent tank supports up to 500 analyses per filling.
User-level management and data traceability support GMP and 21 CFR Part 11 requirements.
Customizable reports can be exported as PDF or printed directly.
Direct balance data transfer is available with specified balance models.
Adjustable RGB color sensor supports AOAC, ISO, PA, and USP methods.
The K1124 autosampler connects directly to the DW-K1160 without an additional power supply.

Applications of Kjeldahl Nitrogen Analyzer

Food and Agricultural Products Industry

Detects protein content in grains, dairy products, meat, beverages, and soy products, as well as specific indicators such as ammonium salts in soy sauce and sulfur dioxide in daylilies; assesses the freshness of aquatic products and meat products (volatile basic nitrogen).

Food and Agricultural Products Industry 21

Feed and Livestock Industry

Accurately determines the crude protein content in feed ingredients and finished products to ensure compliant nutritional ratios in animal husbandry.

Agriculture and Soil Science

Analyzes total nitrogen or ammonium nitrogen in soil, plants, and fertilizers to assess soil fertility and plant nutrient status.

Environmental Monitoring

Detects pollution indicators such as ammonia nitrogen and total Kjeldahl nitrogen in water bodies, sludge, and sediments.

Chemical and Pharmaceutical Industry

Determines the nitrogen content or specific components (such as caprolactam volatile bases) in samples of chemicals, pharmaceuticals, natural rubber, and ores.

Chemical and Pharmaceutical Industry 2 1

FAQ

Automatic models are equipped with automatic pH/potential end-point recognition, no visual observation required. Setting tips: Use 0.1mol/L hydrochloric acid as titrant, and set the end-point pH between 4.6 and 5.0. For samples high in fat and protein, extend the pre-distillation time by 30 seconds appropriately to prevent ammonia volatilization and low test results.

① Incomplete digestion and carbonization caking of samples; ② Insufficient addition of lye leading to incomplete release of ammonia; ③ Water leakage of condenser tube and insufficient steam pressure; ④ Leakage of burette and invalid concentration of standard acid solution; ⑤ Poor sealing of digestion tube causing ammonia leakage.

Run the acid washing and pure water cleaning procedure after each test. For severe crystal blockages, circulate and flush with 5% dilute hydrochloric acid for 10 minutes, then rinse thoroughly with pure water. Drain the lye pipeline if the equipment will be idle for a long time to avoid pipeline blockage caused by ammonium sulfate and salt crystals.

High blank values are mostly caused by impurities in reagents, contaminated glassware or substandard water quality. Solutions: Choose superior pure sulfuric acid and boric acid; use ultrapure water throughout the experiment; pre-burn digestion tubes at high temperature to remove nitrogen-containing impurities; regularly replace fresh standard acid and sodium hydroxide solutions.

The standard cleaning includes three steps:

Flush the titration pipeline with dilute acid to neutralize residual alkaline liquid;

Rinse all distillation, condensation and titration pipelines with sufficient pure water;

Drain the lye delivery pipeline to prevent strong alkali from corroding pump tubes.

Specifications of Kjeldahl Analyzer DW-K1160

DW-K1160 Automatic Kjeldahl Nitrogen Protein Analyzer
Measuring range	0.1mg ～240mg N
Analysis time	3～8min/sample
RSD	≤5%
Recovery	≥99.5%
Burette volume	0.2μL/step, 0.4μL/step and 1.0μL/step optional
Sample capacity	solid≤5g/sample, liquid≤20mL/sample
Water consumption in the distillation process	0.5L/min
Data storage capacity	1 million groups
Interface	USB, LAN, RS232, CAN, WIFI
Power supply	220VAC±10%, 50Hz
Power	2Kw
Net weight	38Kg
Dimensions	460mm×360mm×725mm
DW-K1124 Auto Sampler
Capacity	24 samples per batch
Rotor speed	≥0.04r/s
Sampling speed	≥40mm/s
Tank capacity	4×15L
Interface	CAN
Voltage	24V DC
Rated Power	40W
Dimension(L×W×H)	920mm×625mm×908mm
Weight	80Kg

Item	K1100F	K9860	K9840
Automatic	Y	Y	N
Measuring range	0.1mg～200mg N	0.1mg～200mg N	0.1mg～240mg N
Reproducibility	Average value relative error±0.5%	Average value relative error±0.5%	Average value relative error±0.5%
Recovery	≥99.5%	≥99.5%	≥99.5%
Sample capacity	solid 5g/sample, liquid 20mL/sample	solid 5g/sample, liquid 20mL/sample	solid 5g/sample, liquid 20mL/sample
Water consumption in the distillation process	1.5L/min	1.5L/min	1.5L/min
Data storage	1800 groups	1000 groups	—
Burette volume	1.0μL/step	2.0μL/step	—
Analysis time	3-8min/sample	5～10min/sample	—
Power supply	220VAC±10%, 50/60Hz	220VAC±10%, 50/60Hz	220VAC±10%, 50/60Hz
Power	2KW	2KW	1.3KW

Function	K1100F	K9860	K9840
Steam Flow Adjustment	Y	Y	N
Steam model	Y	N	N
Digestion tube discharge	Y	N	N
Digestion tube cleaning	Y	N	N
Reagents bottle liquid level monitor	Y	N	N
Receiving cup cleaning	Y	Y	–
Burette calibration	Y	Y	–
Data output	Y (optional)	N	N
Method storage	Y	Y	N
Boric acid pipeline cleaning	Y	Y	N
Alkali pipeline cleaning	Y	Y	Y
Safety Door	Y	Y	Y
Digestion tube on position monitor	Y	N	Y
Condensing water flow monitor	Y	Y	Y
Water level monitor	Y	Y	Y
Steam generator temperature overload protection	Y	Y	Y
Steam generator pressure overload protection	Y	N	N
Liquid level monitor for Alkali/ acid/ Distilled water bottle	Y	N	N

Y: with this function.

N: without this function.

-: without this hardware configuration.

Model Selection and Configuration Recommendations

If Need Kjeldahl Method with Digester, you can choose DW-SH220F or SH420F;
Digestion process completed by DW-SH220F Kjeldahl Digester or SH420F Kjeldahl Digester;
Heavy Metal Digestion can choose SH230N Heavy Metal Digester;
