Biochemistry Analyzer

Biochemistry Analyzer

Biochemistry Analyzer

Drawell offers fully automatic and semi-automatic biochemistry analyzers for different laboratory workloads. The range covers compact 200 tests/hour systems up to 600 tests/hour automatic analyzers, with options for STAT testing, refrigerated reagents, automatic dilution, QC management and open reagent methods.

Choose the analyzer according to daily sample volume, required throughput, sample and reagent capacity, automation level and available laboratory space.

TC6090

Features of Biochemistry Analyzer

  1. Fully automatic, discrete, random STAT function.
  2. Online test items.
  3. Analysis Method: end-point, kinetic, two-point, double-reagents, double-wavelength, multi-standard, etc, open to various reagents.
  4. Data Processing.
  5. Various QC managements, insert QC randomly; save, display & print QC chart; define different QC in advance.
  6. Calibration: linear/nonlinear multi-point calibration.
  7. Re-test: retest the sample automatically when the result is out of the linearity range or the sample is not sufficient
  8. Cleaning System,8-step automatic washing, automatic cuvette dry function.

Applications of Biochemistry Analyzer

1. Liver function test: total bilirubin, direct bilirubin, total protein, albumin, alanine aminotransferase, aspartate aminotransferase, γ-glutamyltransferase, alkaline phosphatase.

2. Examination of renal function: urea (UREA), creatinine (CREA), uric acid (UA).

3. Blood lipids: total cholesterol (TC), triglyceride (TG), low-density lipoprotein cholesterol (LDL-C), high-density lipoprotein cholesterol (HDL-C), apolipoprotein (ApoA1), apolipoprotein ( ApoB).

4. Blood sugar: Glucose (Glu), glycosylated hemoglobin (HbA1C) detection.

5. Three items of rheumatism: C-reactive protein, antistreptolysin O, and rheumatoid factor.

Applications of Biochemistry Analyzer

How to Choose the Biochemistry Analyzer?

  1. Start with Daily Test Volume

Do not select an analyzer only by maximum throughput. Consider your normal daily workload, peak-hour sample volume and whether STAT samples need to be inserted during routine testing.

Drawell range: 200–600 tests/hour for fully automatic models.

  1. Check Sample and Reagent Capacity

Higher throughput is useful only when the analyzer also provides enough sample and reagent positions for your workflow.

For example:

  • TC6030: 40 samples / 40 reagents
  • TC6090: 93 samples / 80 reagents
  • TC800: 110 or 165 samples / 80 or 120 reagents
  1. Automatic or Semi-Automatic?

Choose a fully automatic model when reducing manual sample and reagent handling is important.

Choose a semi-automatic analyzer when sample volumes are lower and manual operation is acceptable.

  1. Check Reagent Compatibility

Several Drawell fully automatic models use an open reagent system and support end-point, kinetic, two-point, double-reagent, double-wavelength and multi-standard methods.

Before ordering, confirm the reagent method and required analyzer settings for the assays used by your laboratory.

  1. Check Sample Volume
  • TC800: 1–50 μL
  • TC6090: 2–50 μL
  • TC6030: 2–50 μL
  1. Check Optional ISE Requirements

If K, Na, Cl or other electrolyte testing is required, confirm the available ISE configuration before ordering, as ISE options differ by model.

  1. Confirm Installation Conditions
  • Power supply
  • Available bench/floor space
  • Water consumption
  • Operating temperature and humidity

Order Process

order process

Support for Biochemistry Analyzer Projects

  • Model Selection: Configuration can be selected according to throughput, sample capacity, reagent capacity and automation requirements.
  • Technical Documents: Product brochures and manuals are available for supported models.
  • Installation Preparation: Power supply, water consumption, operating environment and installation dimensions can be confirmed before shipment.
  • Application Confirmation: Reagent methods and analyzer configuration should be confirmed before ordering according to the laboratory’s intended tests.

FAQ

Fully automatic analyzers automate more sample, reagent, reaction and washing steps, while semi-automatic systems require more manual sample and reagent handling.

The TC800 provides up to 600 tests/hour, the highest throughput among the models compared on this page.

The DW-TC220 has a compact body size of approximately 54.8 × 42.2 × 38.3 cm and weighs ≤23 kg.

TC800, TC6090, TC6030 and TC220 documentation lists multiple analysis methods and an open reagent system. Reagent compatibility should still be confirmed for the intended assay before use.

STAT functionality is available on selected fully automatic models, including TC800, TC6090 and TC6030.

Selected automatic models provide refrigerated reagent positions, generally maintained at 2–8°C according to their specifications.

Automatic dilution and re-testing are available on selected fully automatic models. Dilution range and settings vary by model.

Optional ISE configurations are available on selected models. Confirm the required electrolyte parameters before ordering.

Provide your estimated tests per day, peak workload, required assays, preferred automation level, reagent requirements and installation conditions.
