DW-ADQ Series Multi Manifold Rotary Evaporator

The DW-ADQ Series multi-manifold rotary evaporator is designed for parallel concentration of up to five laboratory samples while also supporting conventional single-flask evaporation. Three configurations are available for different batch volumes, with water-bath heating, stepless rotation, automatic lifting and optional vacuum control.

Parallel Sample Positions: 5
Multi-Flask Capacity: 5 × 50 / 5 × 100 / 5 × 150 mL
Single-Flask Capacity: 25–2000 / 25–3000 / 25–5000 mL
Rotation Speed: 0–310 rpm
Water Bath: RT–99°C ±0.5°C
Automatic Lifting Stroke: 150 mm

ADQ Series Brochure

Description

Features of Multi Manifold Rotary Evaporator

Processes up to five samples simultaneously with 5 × 50 mL, 5 × 100 mL or 5 × 150 mL configurations.
0–310 rpm rotation, adjustable rotation speed with LCD display and knob control.
The 0–60 s adjustable interval supports compatible powder drying workflows.
PID water bath, heating from room temperature to 99°C with automatic temperature control.
Teflon composite bath, provides corrosion resistance, high temperature resistance and easier cleaning.
Large area condenser, designed with a drip point and anti backflow structure for solvent recovery.
The mechanical flask removal device simplifies installation and disassembly.

Optional Vacuum Control

Standard: Suitable for laboratories using an existing external vacuum-control setup.

Vacuum Control: Includes a built-in vacuum controller for setting the required vacuum level during evaporation.

Setting Range: 0–1013 mbar
Accuracy: ±1

Standard or Vacuum Control Configuration

Optional Configuration & Protection

Optional Vacuum Control: Built in vacuum controller with a 0–1013 mbar setting range and ±1 accuracy.
Overtemperature Protection: Heating stops automatically when the bath temperature exceeds the preset value.
Protective Bath Cover: Helps reduce heat loss and limits splashing during operation.

Technical Parameter

Model	DW-2000ADQ		DW-3000ADQ		DW-5000ADQ
Type	Standard	Vacuum control	Standard	Vacuum control	Standard	Vacuum control
Rotating Speed	LCD display 0~310rpm/min		LCD display 0~310rpm/min		LCD color screen display 0~310rpm/min (3L inner rotating bottle up to 310rpm/min)
Vacuum	The vacuum inside the device can reach 2mbar
Vacuum control	/	Built-in vacuum controller (arbitrary control experiment required vacuum degree, setting range: (0~ -0.1Mpa) 0~1013mbar; Accuracy ±1).	/	Built-in vacuum controller (arbitrary control experiment required vacuum degree, setting range: (0~ -0.1Mpa) 0~1013mbar; Accuracy ±1).	/	Built-in vacuum controller (arbitrary control experiment required vacuum degree, setting range: (0~ -0.1Mpa) 0~1013mbar; Accuracy ±1).
Temperature range	Water bath: room temperature ~99℃±0.5℃;
Material	Disposable Teflon coating, easy to clean.The heating pan has a safety handle,and equipped with a protection cap.
Size	φ23×13cm		φ26×15cm		φ29×17cm
Sample bottle	Intermittent rotation around, intermittent time adjustable 0 ~ 60s, can be used for drying powder samples.
Rotating glass shaft	29#/42 grinding integrated glass shaft, evaporation bottle fixing clip connected to the bottle remover, to prevent loss.		29#/42 grinding integrated glass shaft, length 235mm, evaporation bottle fixing clip connected to the bottle remover, to prevent loss.		29#/42 grinding integrated glass shaft, length 235mm, evaporation bottle fixing clip connected to the bottle remover, to prevent loss.
Lift stroke	Touch + handle type double automatic balancing lifting (lifting stroke 150mm) The descending end point has a fixed 60mm safety distance to prevent collision.
Temperature Control	Microcomputer PID controller, digital display.
Temperature setting	Knob encoder, rotary input setting, large LCD screen display, convenient and fast
Safety performance	Timing function (0~999min) : After reaching the predetermined time, the device will automatically stop working and return to the standby state; Overtemperature warning: The instrument automatically raises the evaporation bottle for standby warning protection
Heater	Fully enclosed heater
Power	1.5KW		1.5KW		1.8KW
Usable capacity of sample bottle	5 *50ml or single (25~2000mL)		5 *100ml or single (25~3000mL)		5 *150ml or single (25~5000mL)
Sealing unit	Imported PTFE and special synthetic materials are processed and synthesized by special process technology to enhance sealing, corrosion resistance and wear resistance.
Condensing pipe	Vertical, three-layer ball grinding mouth snake condensing pipe,condensing area of 0.18m², with dripping point and anti-backflow design.		Vertical, three-layer ball grinding mouth snake condensing pipe,condensing area of 0.21m², with dripping point and anti-backflow design.		Vertical, three-layer ball grinding mouth snake condensing pipe,condensing area of 0.31m², with dripping point and anti-backflow design.
Service ambient temperature	5~40℃
Voltage	AC220V/50HZ
Instrument size	660420830mm		700430860mm		740440960mm
Package size	710645510mm		710645790mm		780690850mm
Gross weight	30kg		35kg		42kg

Applications of Multi Manifold Rotary Evaporator

Parallel Sample Concentration

Used for simultaneous concentration of multiple compatible small-volume liquid samples under the same general evaporation workflow.

Laboratory Sample Preparation

Supports evaporation of multiple laboratory solutions and extracts before subsequent testing or processing.

Small-Batch R&D

Useful when several formulation, reaction or extraction samples need to be processed under comparable conditions.

Powder Drying

Intermittent forward/reverse rotation supports compatible powders and solid samples during reduced-pressure drying.

FAQ

The system can process up to five samples simultaneously. DW-2000ADQ supports 5 × 50 mL, DW-3000ADQ supports 5 × 100 mL, and DW-5000ADQ supports 5 × 150 mL.

Yes. It supports both multi-flask and single-flask operation. The single-flask ranges are 25–2000 mL, 25–3000 mL and 25–5000 mL, depending on the model.

The rotation speed is adjustable from 0 to 310 rpm. For DW-5000ADQ, the brochure specifies up to 310 rpm when using an inner rotating flask up to 3 L.

The water bath operates from room temperature to 99°C ±0.5°C with microcomputer PID temperature control.

Yes. The forward and reverse rotation interval can be adjusted from 0 to 60 seconds for compatible powder-drying workflows.

Yes. A Vacuum Control configuration is available with a built-in vacuum controller.

The built-in vacuum controller provides a setting range of 0–1013 mbar with a specified accuracy of ±1.
