LVDV-1 Digital Viscometer

Options of LVDV-1 Digital Viscometer

1. Extreme low viscometer adapter (with one spindle L0)
2. Small sample adapter (with spindle 21, 27, 28 and 29 each)
3. Temperature-controlled heater (with spindle 21, 27, 28 and 29 each)
4. Spindle R1
5. Special software that can complete the function in collecting the data automatically
6. DV program control download software
7. Specially used printer

The main technical indicators of LVDV-1 Digital Viscometer

Measuring Range（mPa·s）	12～6,000,000
Rotating Speed (RPM)	0.1 ～ 99.9 （Stepless Gear）
Number of Spindles	Spindles (Code L1,L2,L3,L4) are equipped with the product
Accuracy	±1% full scale range in use
Repeatability	±0.5% full scale range in use
Readability	1.when viscosity is lower than 10.0 cp : 0.01 2.when viscosity is lower than 10000 cp : 0.1 3.when viscosity is equal or higher than 10000 cp : 1
Power	Power adapter ( input: 100-240V，50/60Hz)
LCD screen display	The LCD screen can display the viscosity, speed, torque spindle, temperature and the maximum viscosity can be measured in the current spindle speed value.

Apparatus to be equipped of LVDV-1 Digital Viscometer

digital viscosity meter	1 pce	ascending and falling rack	1 set
standard spindle	1 set	power adapter	1 pce
protective frame of spindle	1 pce	spanner	1 pce
Seat and leveling feet	1 set	RS232 standard output interface	1 pce
RTD temperature probe	1 pce

Popular Digital Viscometer Comparison

Key Parameter	Drawell RVDV-2	Brookfield DV2Plus RV	Anton Paar ViscoQC 300 R
Viscosity Range	40–40,000,000 mPa·s	100–40,000,000 mPa·s	1.3–40,000,000 mPa·s
Speed Range	0.1–200 RPM, stepless	0.1–200 RPM	0.01–250 RPM
Accuracy	±1% F.S.	±1% of range	±1% F.S.
Standard Spindles	6 × R-Series	6 × RV	R-Series system

Drawell provides a practical alternative for laboratories that need wide viscosity coverage, flexible speed control and multiple model options for low-, medium-, high- and high-temperature viscosity testing.
