Automatic Refractometer Series

The automatic refractometer is equipped with high performance linear CCD photosensitive components, with a high speed, high precision signal collection, and analysis processing technology, equipped with a semiconductor parr super temperature control system. Can high efficiency, high precision measurement of sugar solution(hammer) degrees Brix

Improve innovative efficiency

1. 7 inch colour touch screen;

2. Level sapphire prism;

3. high resolution CCD sensor.

Automatic Refractometer Series

The main technical indicators

Model

JH200

JH300

Range

1.3000—1.7000(nD)

1.3000—1.7000(nD)

Fine degrees

±0.0002

±0.0002

Sugar range

0—100%(Brix)

0—100%(Brix)

Sugar  accuracy

±0.1%(Brix)

±0.1%(Brix)

Temperature control

NO

Built-in semiconductor

Temperature control range

RT

5℃—65℃

Stability of temperature control

RT

±0.03℃

Light source

LED light source

LED light source

Wave length

589nm

589nm

Edge mirror

sapphire level

sapphire level

Samples pool

stainless steel

stainless steel

Test method

CCD linear CCD

CCD linear CCD

Display way

FTF color touch screen

FTF color touch screen

Data interface

USB RS232

USB RS232

Power source

220V/50HZ

220V/50HZ

Application field

Automatic refractometer has widely used in petroleum industry, pharmaceutical industry, food industry, daily chemical industry, sugar industry, etc, is one of the schools and the relevant scientific research units of commonly used equipment.

Automatic Refractometer Series

Conform to the standard

Drawell series refractometer in with international standards, such as ASTM, ICUMSA, OILM, AOAC, DIN/ISO, FDA, the ISI, JIS and pharmacopoeia, and fully meet the requirements of the 21 CFR part 11 user level audit trails, tamper-proof electronic signature and data output, etc.

The main technical indicators

Model

JH500

JH600

Range

1.30000—1.70000(nD)

1.30000—1.70000(nD)

Fine degrees

±0.00003

±0.00002

Sugar range

0—100%(Brix)

0—100%(Brix)

Sugar accuracy

±0.1%(Brix)

±0.1%(Brix)

Temperature control

Built-in semiconductor

Built-in semiconductor

Temperature control range

5℃—65℃

5℃—90℃

Stability of temperature control

±0.02℃

±0.01℃

Light source

LED light source

LED light source

Wave length

589nm

589nm

Edge mirror

Sapphire level

Sapphire level

Samples pool

Stainless steel

Stainless steel

Test method

CCD linear CCD

CCD linear CCD

Display way

FTF color touch screen

FTF color touch screen

Data interface

USB RS232

USB RS232

Power source

220V/50HZ

220V/50HZ
