Model

FD36A

FD36R

FD50A

FD50R

FD80A

FD80R

FD100A

FD100R

Capacity(L)

36

50

80

100

Outer dimension(mm)

460x542x960

460x542x1070

620x680x1042

620x680x1222

Sterilization chamber size(mm)

325×460

325×670

400×709

400×889

Rated power supply

220V 50Hz/60Hz

Rated power(W)

2300

2600

4600

4600

Working environment

5℃-40℃, relative humidity 10%-85%

Chamber material

SUS 304 stainless steel

Sterilization temperature

105-135℃

Sterilization time

1-300 min

Drying Time

1-300 min( only available for Type R)

Range of pressure gauge

0-0.4Mpa

Controller

Microcomputer control system

Mode

Solid mode, liquid mode, drying function of Type R

Safety Device

Self-induction interlocking device, over temperature protection system,dry scorch protection, over pressure protection, safety valve, over current and short circuit protection, cover checking system, electric leakage protection, scald protection, automatic failure-inspection system

Standard accessories

Stainless steel bakets,waste bottle, water plate, drainage hose

Optional parts

Printer, printing set, stainless steel pails
