DTR3200 Portable Raman Spectrometer

DTR3200 portable Raman spectrometer is an ideal instrument for scientific research, in the medical instrument industry.
It integrates two-wavelength laser sources to fit the application of uncertain wavelengths. It requires no contact, and no treatment to make an undestructive detection. This instrument has the advantages of high performance-to-ratio, smart size can detect liquids, including fabrics, biology, alcoholics, crystals, etc.

Features of DTR3200 Portable Raman Spectrometer

  1. Dual bands : 532, 633, 785, 1064nm (optional dual wavelengths combination);
  2. High sensitivity, SNR>3000:1
  3. High Stability
  4. Hamamatscu CCD, excellent performance ;
  5. High performance spectrometer
  6. USB2.0 connect to PC

Application of DTR3200 Portable Raman Spectrometer

  1. Scientific Research
  2. Biology Science
  3. Forensic Science
  4. Material Science
  5. Medical Immunology
  6. Agriculture and food identification
  7. Water Pollution analysis
  8. Gemstones and inorganic mineral
  9. Environment Science

Specifications of DTR3200 Portable Raman Spectrometer

Types

DTR3200-532nm

DTR3200-633nm

DTR3200-785nm

DTR3200-830nm

DTR3200-1064nm

Interface

USB 2.0

USB 2.0

USB 2.0

USB 2.0

USB 2.0

Integration
Time

1ms 120s

1ms -64s

4ms – 120s

4ms – 120s

4ms – 120s

Power
Voltage

AC 220V(+/-5%)

AC 220V(+/-5%)

AC 220V(+/-5%)

AC 220V(+/-5%)

AC 220V(+/-5%)

Working
Temperature

-10〜40



-10—0

-10〜40

-25〜50

-10—0

Working
Humidity

< 95%

< 95%

< 95%

< 95%

< 95%

Size
(L*W*H)
(mm)

800*500*300

800*500*300

800*500*300

800*500*300

800*500*300

Channels
No.

100

100

100

100

100

Rail
Accuracy

0.625 pm

0.625pm

0.625pm

0.625pm

0.625pm

Weight

12Kg

13Kg

12Kg

12Kg

14Kg

Reliability











Spectral
Stability

σ/μ < 0.5%
(COT 8 hours)

σ/μ< 0.5%
(COT 8 hours)

σ/μ< 0.5%
(COT 8 hours)

σ/μ< 0.5%
(COT 8 hours)

σ/μ< 0.5%
(COT 8 hours)

Temp
Stability

shift < 1 cm-1
(10-40)

shift < 1 cm-1

(10-40 )

shift < 1 cm-1

(10-40 )

Shift <1 cm-1
(10-40)

Shift <1 cm-1
(10-40)

Spectral
intensity
change (in 5
40)

〈士5%

<5%

<5%

<5%

<5%

Optical
parameters











SNR

>1500:1

>3000:1

>3000:1

>3000:1

>3000:1

Detector











Models

High sensitivity
Cooled CCD

High sensitivity
Cooled CCD

High sensitivity
Cooled CCD

High sensitivity
Cooled CCD, Raman
signal enhanced
back-thinned CCD

High sensitivity
512 pixels InGaAs
detector

Detector
cooled Temp

-10

-10

-10

-10

-20

Detector
Range

200-1100nm

200-1100nm

200-1100nm

200-1180 nm

900-1700nm

Dynamic
Range

50000: 1

10000 1

50000 1

30000 1

80000 1

Excitation











Central
Wavelengths

532nm0.5nm

633nm±0.5nm

785nm±0.5nm

830 nm±0.5nm

1060.5nm

PWHM

0.1 nm

 0.1 nm

0.08 nm

0.1 nm

0.1 nm

Max. Power

100mW

100mW

500 mW

500 mW

500 mW

Power
Stability

σ/μ <±0.5%

σ/μ  <±0.5%

σ/μ <±0.2%

σ/μ <±0.2%

σ/μ  <±0.2%

Raman
Probe











Working
Distance

6 mm

6 mm

6 mm

6 mm

6 mm

OD

OD>8

OD>8

OD>8

OD>8

OD>8

NA

0.3

0.3

0.3

0.3

0.3

Aperture

7mm

7mm

7mm

7mm

7mm

Operation
System

Android

Interface

WIFI, 4G (optional)

System parameters

Interface

USB 2.0

Operation Mode

Touch screen,PC

Power supply

110-220V,0.5A

Integration Time

4ms-120s

Power Voltage

DC19V(+/-5%)

Power

Max. Power:50W

Working Temp.

-10~50

Working Humidity

<95%

Size(L*W*H)

350(d) x 296(w) x 172(h) mm

Weight

12kg
