TOC Analyzer DW- DI1500 – OL

TOC analyzer (Total Organic Carbon, referred to as TOC) is the total organic carbon analyzer. It is a comprehensive index to express the total amount of organic matter in the water body with the content of carbon. TOC can be used directly to represent the total amount of organic matter. Therefore, it is used as an important reference index to evaluate the degree of organic pollution in water bodies.

Applications of TOC Analyzer DW- DI1500 – OL

Detect the Total Organic Carbon in Water For Injection (WFI), ultra-purified water of pharmaceutical and semi-conductor industries;

Deionized (DI) water of power plant.

Features of TOC Analyzer DW- DI1500 – OL

  • IP65 Protection,4-20mA Output
  • Various control methods are available

Controlled by PC or IPC.

Suitable for various work scenarios, conforming to stand-alone data integrity, and linked to MES systems via transmitters.

  • Flexible installation

Wall-mounted, clip-on, desktop, embedded, and other installation methods can be selected.

  • Remote data transmission

Multi-signal output, such as analog signals and digital signals, can be linked with the water system.

  • Multi-channel transmitter

It can realize data transmission of temperature, TOC value, conductivity, PH value, dissolved oxygen, etc.

  • Disassembly-free design

UV lamps and pumps are easy to be replaced and maintained

Easy to operate and maintain.

  • Data Integrity

Fully comply with GMP and 21 CFR Part 11 requirements for electronic data integrity with four levels of password authority, audit trail function, and various forms of backup.

Technical Parameters of TOC Analyzer DW- DI1500 – OL

Detection range:(0- 1500.0)µg/L

Recommended range of water sample conductivity:(0-5. 1)µS/cm @25C

Power supply:(100-240) VAC

Testing time:3 min

Rated power:100W

Ambient temperature:(10-60)C

Indication error:±5%



Sample temperature:(1-95)C
